型号Model
|
32-5RZ
|
||
|
项目
|
单位
|
值
|
|
| 泵送系统Pumping system | 最大理论输送量Max. Theor. output(high pressure) | m3/h | 100 |
| 混凝土最大理论出口压力Max. Theor. concrete output Pressure(high pressure) | MPa | 7.3 | |
| 料斗容积 Hopper capacity | L | 600 | |
| 上料高度 Filling height | mm | 1400 | |
| 液压系统型式 Hydraulic system type |
|
开式 | |
| 分配阀形式Distribution valve |
|
S管阀 S valve | |
| 油缸缸径×行程 Oil cylinder dia.×stroke | mm | φ110×1400 | |
| 混凝土缸径×行程Concrete cylinder dia.×stroke | mm | φ230×1400 | |
| 液压油冷却Hydraulic oil cooling |
|
风冷Air cooling | |
| 臂架Placing boom | 结构形式 Structure type |
|
32-5RZ |
| 最大布料高度 Placing depth | m | 32 | |
| 最大布料半径 Horizontal distance | m | 27.1 | |
| 回转角度Slewing angle |
|
±360° | |
| 输送管直径 Pipe diameter | mm | 125 | |
| 末端软管长度End hose length | mm | 3000 | |
| 臂架最小打开高度Min. height of opening placing boom | m |
5.8
|
|
| 支腿跨距（前×后×纵向）Outriggers span (front×rear×side) | mm |
5950×6270×5350
|
|
| 底盘及整车Chassis and the whole machine | 整车重量total weight | t | 20 |
| 轴距 Wheelbase | mm | 4600 | |
| 发动机型号Engine type |
|
玉柴 | |
| 发动机额定功率 Engine power | kW | 176kw | |
| 燃油箱容积Oil tank cubage | L | 300 | |
| 尾气排放标准Tail gas exhaust standard |
|
国VI | |
| 整车外形尺寸(长×宽×高) Overall dimensions | mm | 9100×2400×3500 | |
| 液压油箱容积 Oil tank volume | L | 600 | |
| 控制方式Control mode |
|
手动+遥控Manual＋remote control | |
| 混凝土管清洗方式Pipe cleaning mode |
|
水洗/干洗Water cleaning/dry cleaning | |
