Max.theo.output volume of foamed concrete:80m³/h
Max theo.pumping pressure:12.5Mpa
The maximum pumping frequency: 26(Low voltage);16(high-pressure)Once/min
Conveying height:180m
Max.theo.output volume of foamed concrete:80m³/h
Max theo.pumping pressure:12.5Mpa
The maximum pumping frequency: 26(Low voltage);16(high-pressure)Once/min
Conveying height:180m
Item | Unit | parameter | |
Overall performance | Max.theo.output volume of foamed concrete | m³/h | 80 |
Max theo.pumping pressure | Mpa | 12.5 | |
The maximum pumping frequency | Once/min | 26(Low voltage);16(high-pressure) | |
Conveying height | m | 180 | |
Max.theo.transport distance | m | 700 | |
Specification of conveying cylinder | mm | Φ200×1650 | |
Master cylinder specification | mm | Φ125/Φ80×1650 | |
fuel tank capacity | L | 420 | |
Hopper capacity | L | 600 | |
Feeding height | mm | 1400 | |
Discharging outlet diameter | mm | Φ150 | |
Delivery pipe diameter | mm | Φ125 | |
Power system | power of motor | Kw | 110 |
Voltage | V | 380 | |
Rated speed | r/min | 1480 | |
Hydraulic pressure system | Hydraulic circuit form |
|
Open loop |
Maximum oil pressure of pumping system | MPa | 32 | |
Maximum oil pressure of mixing system | MPa | 14 | |
Maximum stirring speed | r/min | 24 | |
Othersparameter | Slump range | mm | 80~200 |
The maximum aggregate size | mm | pebble50,broken stone40 | |
Overall dimensions | mm | 6170×1930×2100 | |
Main engine weight | Kg | 5200 | |
Towing speed | Km/h | ≤8 |
